Paper Roll Handling Device

Product Appearance
The device features a robust, low-profile steel frame with a compact design to maximize maneuverability in tight spaces. Its main arms are equipped with large, bright orange polyurethane-coated contact pads, providing high visibility and scratch-resistant protection for paper surfaces. A centralized control box with an ergonomic pendant ensures clear visibility and easy operation.

Mechanism Design
At its core, the device utilizes a self-centering scissor mechanism. As the arms close, they automatically align to the roll's center of gravity, ensuring a balanced lift. The gripping force is applied synchronously by dual hydraulic cylinders, offering precise and adjustable pressure control to suit different roll weights and diameters without compromising the paper's integrity.

Standard Parts
For reliability and easy maintenance, the device incorporates high-quality standard components. This includes ISO-interchangeable hydraulic cylinders, universal rotating bearings, and standardized hoses and fittings. The electrical system features common industrial-grade connectors and a proven motor-pump unit, ensuring compatibility and simplified servicing worldwide.
