Wall Travelling Jib Crane

Product Appearance

This crane features a clean, robust steel structure with a long horizontal jib arm mounted on a trolley. The trolley moves smoothly along a high-strength I-beam runway securely fixed to the building wall or support columns. Its compact profile minimizes obstruction. Standard finishes include industrial-grade paint, and the hoist unit is neatly integrated onto the trolley, presenting a professional and functional aesthetic.

Mechanism Design

The core mechanism involves two independent motor-driven movements: traverse and hoisting. An electric travel drive powers the trolley's movement along the runway beam, allowing full coverage of the work area. A separate hoist unit, mounted on the trolley, handles precise vertical lifting and lowering. This dual-motor design, often equipped with variable speed control, ensures smooth, accurate, and safe load positioning.

Standard Parts

To ensure reliability and interchangeability, the crane utilizes high-quality standard components. These typically include a branded electric chain hoist or wire rope hoist (e.g., from CM, Kito, or equivalent), frequency inverters for control, end stops, limit switches for travel and hoisting, and industrial-grade wheels and track. Electrical cabinets, push-button pendants, and festooning systems for power supply are also standard, guaranteeing safe operation and easy maintenance.
