Gantry Crane End Carriage

Product Appearance
The end carriage features a robust welded steel frame with a compact, streamlined design. Its surface is treated with anti-corrosion coating, providing a rugged industrial finish in standard grey or customizable colors. The assembly includes clearly visible wheel flanges, connecting plates, and bolt holes, reflecting a neat and functional layout designed for easy integration with crane girders.

Mechanism Design
Equipped with high-strength forged wheels and precision-machined axles, the carriage ensures stable and low-friction travel. It incorporates a sealed drive motor and reduction gearbox, delivering consistent torque and speed control. Optional frequency drive systems allow adjustable traversing speeds. The design also includes bolt-on buffer pads and limit switches for enhanced safety and impact protection.

Standard Parts
Key standard components comprise forged steel wheels, hardened steel axles, premium deep-groove ball bearings, and replaceable rail grips. All fasteners, such as high-tensile bolts and nuts, comply with ISO standards. Electrical fittings include IP-rated junction boxes and pre-wired cable carriers. These standardized parts ensure compatibility, simplify maintenance, and extend service life.
